Shacman X3000 6×4 Dump Truck
380 / 400 / 430 HP
Technical Data
Full Specifications
| Brand & Model | Shacman Delong X3000 |
| Type | Dump truck / tipper |
| Drive | 6×4 |
| Engine options | Weichai WP10.380E22 / WP12.400E201 / WP12.430E201 |
| Power | 380 / 400 / 430 HP (279 / 294 / 316 kW) |
| Torque | 1600 / 1900 / 2100 N·m |
| Displacement | 9.7 L / 12 L |
| Gearbox | Fast 10JSD180 / 12JSD200T (with QH50 PTO) |
| Clutch | Φ430 mm single-plate dry |
| Wheelbase | 3775 + 1400 mm (heavy-load standard) |
| Front axle | MAN 9.5 t |
| Rear axle | MAN 16 t, two-stage reduction, ratio 4.769 / 5.262 / 5.92 |
| Frame | 850 × 300 mm (8+7) reinforced |
| Tyres | 12.00R20 steel-wire (10 pieces) |
| Fuel tank | 300–400 L aluminum alloy |
Built To Order
Customization Options
Engine & Gearbox
Choose 380 / 400 / 430 HP Weichai engine paired with a 10- or 12-speed Fast gearbox to match your duty cycle.
Rear Axle Ratio
Three MAN rear axle ratios available (4.769 / 5.262 / 5.92) depending on use case — highway speed or heavy-load mining.
Cargo Box Shape
Box shape and dimensions can be customized — U-shape, rectangular, well-type or mining-specific configurations on request.
Color
Truck color can be customized on request to match your fleet identity.
Steering
Left-hand or right-hand drive available on request.
Budget-Tailored Solutions
Special services and refurbishment scope tailored to your budget — we adjust which areas are refurbished based on your budget and the refurbishment facility's capabilities, to help control overall cost.
Tell us your requirements and budget — we'll build a solution to match.
Get in Touch
Request a Quote
Pricing is tailored to your chosen engine/gearbox spec, rear axle ratio, cargo box shape, refurbishment scope and destination port. Submit your details and our export team will respond within 24 hours.
