Shacman 8×4 Heavy Duty Truck
380 / 400 / 430 HP
Technical Data
Full Specifications
| Brand | Shacman |
| Drive | 8×4 (4 front + 8 rear wheels) |
| Engine options | Weichai WP10.380E22 / WP12.400E201 / WP12.430E201 (big-pump) |
| Power | 380 / 400 / 430 HP (279 / 294 / 316 kW) |
| Torque | 1600 / 1900 / 2100 N·m |
| Displacement | 9.7 L / 12 L |
| Gearbox | Fast 10JSD180 / 12JSD200T (10 or 12 speed) |
| Clutch / PTO | QH50 power take-off |
| Wheelbase | 1800 + 3575 + 1400 mm (standard) |
| Front axle | MAN 9.5 t |
| Rear axle | MAN 16 t, two-stage reduction, ratio 4.769 / 5.262 |
| Tyres | 12.00R20 steel-wire (12 pieces) |
| Fuel tank | 400 L aluminum alloy |
Built To Order
Customization Options
Body Type
Chassis is configurable for multiple body types — dump truck, concrete mixer, fuel tanker, cargo or other specialized configurations on request.
Engine & Gearbox
Choose 380 / 400 / 430 HP Weichai engine paired with a 10- or 12-speed Fast gearbox to match your duty cycle.
Rear Axle Ratio
Two MAN rear axle ratios available (4.769 or 5.262) depending on use case — speed-biased highway haul or heavy-load low-speed work.
Color
Truck color can be customized on request to match your fleet identity.
Steering
Left-hand or right-hand drive available on request.
Budget-Tailored Solutions
Special services and refurbishment scope tailored to your budget — we adjust which areas are refurbished based on your budget and the refurbishment facility's capabilities, to help control overall cost.
Tell us your requirements and budget — we'll build a solution to match.
Get in Touch
Request a Quote
Pricing is tailored to your chosen body type, engine/gearbox spec, refurbishment scope and destination port. Submit your details and our export team will respond within 24 hours.
